Compact sweepers

The SAMI compact series sweeper is an efficient tool for maintaining hard-surfaced roads and areas.

Compact sweeper SW-1800

Features

Turning angle

Compact tractor sweeper can be turned hydraulically up to ±25 degrees.

Support wheels

Support wheels ensure optimal sweeping height and unifrom wear of the bristles.

Maximum use

The height of the sweeper can be adjusted according to the wear of the brush, allowing maximum use of the brush rings.

Rootorharjad-beeline-harjakettad

Beeline®

All SAMI sweepers use high-quality Beeline® brush rings produced in Finland.

Product code
438.000
Working width (mm)
1800
Width (mm)
2048
Height (mm)
647
Length (mm)
1158
Brush diameter (mm)
Ø550
Turning angle (°)
±25
Weight (kg)
190
Oil flow (min. - max.) (l/min)
30 - 60
Oil pressure (max.) (bar)
200
1/2” couplings
2 pairs
Rec. tractor weight (t)
1,5 - 3
Rec. tractor power (hp)
35 - 70
Rec. working speed (km/h)
5 - 10
Standard equipment
Hydraulic turning angle
Fastenings
All the most common fastenings
Material
Made from SSAB steel
Additional equipment
Product code
Description
438.700
Light water system for SW-1800 sweeper (pipe with nozzles)
438.710
Water tank set 600l (3P cat. 1 & 2) (tank + 12V pump + holder)
438.720
Pump set (12V pump + bracket + hose + cable)
438.730
Dust cover
438.750
LED lights set (lights + cable)
11.900
Hydraulic onversion set
