Turf snow plough TSP-4000

Features

Side wings

Both side wings are hydraulically adjusted and separately controllable. This makes operating between obstacles (e.g., football goals) much easier.

Plough design

Thanks to the smart design, the plough is sturdy and withstands significant loads while still being lightweight. The work can also be carried out by a small tractor or loader.

Support wheels

The durable support wheels of the plough on pneumatic tyres rotate 360 degrees around their support axis and do not damage the grass.

Working height

The working height of the plough can be changed by adjusting the support wheels. The wheels keep the plough blade at the required working height and prevent cutting into the grass.

Blades

The plough's working blades are easily replaceable. Blades made of different materials can be used on the plough, depending on the grass properties and the groundskeeper's wishes: rubber, polyurethane (pur), textile, or rubber composite.

Working width (mm)
4020
Height (mm)
530
Depth (mm)
690
Weight (kg)
330
Turning angle (°)
-
Turning angle of wings (°)
25
Blade angle (°)
0
Oil flow (min. - max.) (l/min)
30 - 60
Oil pressure (max.) (bar)
200
1/2” couplings
1 pair
Rec. tractor power (hp)
30 - 70
Standard equipment
Support wheels
Additional equipment
PUR blades
Fastenings
3P (cat.1) / A frame
Material
Made from SSAB steel
